19. Instrument Installation

The instrument installation is in designing, specifying, procuring, calibrating, installing, piping, loop checking, commissioning and maintaining instrumentation and control systems for a wide range of industrial and commercial process controls, ensuring that the plant operates safely.

Hazard Category	Hazards	Controls
Defective Equipment	1. Accidents can occur    through the use of    faulty and/or defective    or by the installation of    equipment with    insufficient rating for    the task	1. All equipment shall be visually inspected for defects     prior to installation. 2. All equipment being installed shall comply with relevant    ACOP(Approved Code of Practice)'s and safety standards    and be the correct rating for the task.
Nips, Cuts and/or  Abrasions	1. Can occur through     contact with sharp    edges on instruments or    if hands and fingers    become trapped during    the installation process.	1. Personnel protective equipment (PPE) shall be worn at      all times when handling sharp or otherwise potentially     hazardous materials. 2. A "Safe System of Work" shall be implemented to     reduce the possibilities of accidents/incidents caused by    a lack of communication, utilizing "Tool box talks"    (if necessary). 3. All sharp edges shall be removed or dressed immediately.
Falls of Materials  and/or Tools	1. Accidents can occur    through items being    dropped during the    installation process.	1. Materials and tools shall be kept secure at all times    during the installation process. 2. Barriers shall be erected beneath the installation area to     restrict access of other personnel (where required). 3. Alternative access shall be made available if the normal     access/egress is obstructed.
Fall of Personnel	1. Accidents can occur if     suitable access/egress is    not provided and    maintained to the    installation area at all    times, during the    installation process	1. Safe access/egress shall be maintained to the work area     at all times. 2. Please refer to relevant risk assessment, i.e. working on      scaffolding, working off ladders, working off stepladders

계장기기/기구/장치/케이블 등등 모든 작업을 여기에 기재 할 수 없죠!!

JSA(Job Safety Analysis) 를 준비할 때에 관련된 작업내용을 같이 확인해보시길 바랍니다.

Process Safety (공정안전)에 관심이 있으시면, P&ID 부터 시작하세요~
